Make Your Own Diagnostic Equipment (MYODE) - Runs on all Phones & Tablets(Includes circuit explanations, parts list and detailed explanation on how to build)By Mandy ConcepcionThis book-APP, “Make Your Own Diagnostic Equipment” came about from the need of many readers and viewers to be able to make and maintain fairly simple diagnostic gadgets. It is meant to show and guide the professional technician and DIY mechanic on how to make these gadgets. In many cases, due to the nature of the equipment industry, it is very expensive or virtually impossible to get these tools. The reason being is that often times tool makers don’t see a profit in making these simple but effective gadgets. Most, if not all of these tools, are invaluable in diagnosing modern automotive systems. You can estimate that having one of these tools, at the right time when needed, will cut your diagnostic time by at least 50%. Of course, knowing how to use it is also important. However, by definition if you’ve already studied how the gadget works, how to build it an also ended up building it yourself, you’ve already passed the learning curve and chances are you’ll know how to use it. At the very least, reading this book will put you in a much better position to also asses diagnostic issues and on the use of other important tools of automotive diagnostics.
It is our hope with this work to enlighten the professional and DIY mechanic on the use, construction and operation of modern automotive diagnostic gadgets. Use this information to the beast of your abilities and be on the diagnostic driver seat.
Table of Contents
Automotive Low Pressure TransducerBuilding the Low Pressure TransducerUsing the Low Pressure TransducerPolarity LED Test LightUsing the Polarity LED Test LightStress Loaded Test LightUsing the Stress Loaded Test LightBuilding the Stress Loaded Test LightFuel-Pump Relay & the Stress Loaded Test LightDual Polarity & 5 Volt Reference Test LightAmplified Sensor TesterInjector & Coil Magnetic DetectorFuel Injector PulserECM-ECU Memory Saver ToolLoaded Injector Noid LightUsing the Loaded Injector Noid Light5 Volt Reference SimulatorParasitic Draw Amp MeterUsing the Parasitic Draw Amp MeterFuse Voltage Drop Short IdentifierHow to Use the Fuse Voltage Drop Short IdentifierIgnition Primary DIS - COP ProbeHow to Use the Ignition Primary DIS ProbeDrive-By-Wire Motor Actuator ControllerHow to Use the Drive-By-Wire Actuator ControllerIgnition Key Transponder DetectorUsing the Ignition Key Transponder DetectorMagnetic Sensor Induction SimulatorUsing the Magnetic Sensor Induction SimulatorO2 Sensor SimulatorUsing the O2 Sensor SimulatorABS Speed Sensor SimulatorUsing the ABS Speed Sensor SimulatorABS Speed Sensor Simulator, Bleeding the BrakesOptical CAM and CRANK Sensor SimulatorUsing the Optical CAM and CRANK Sensor SimulatorOBD-2 Data Link Connector Breakout BoxUsing the OBD-2 DLC Breakout Box
